When I connected the USB Wifi dongle based on Realtek RTL8188GU chip into my Beaglebone Black (BBB) Rev. C running Debian 12 (Linux BeagleBone 6.15.7-bone21) the device was recognized via lsusb but it didn’t work. Here I share the steps I did to make it work. This might also work to Raspberry Pi and others single-board computers.

Just for reference, below is the photo of the dongle that I have attached to the BBB.

wifi-dongle-bbb

Before start, there are a couple of things you should to know:

  1. My BBB is totally headless, no GUI at all only terminal.
  2. I used the image BeagleBone Black Debian 12.11 2025-06-30 IoT-VSCode.
  3. My BBB was connected to my main PC (running Windows 11) via USB cable. So I could access it via SSH.
  4. I set my Win 11 to share the internet connection with the BBB. So when I need to download anything I could do it directly from the BBB.

Step 1 – Identify the dongle with lsusb

This is an important step. We need to know that is there and if the Kernel have identified it:

$ lsusb
Bus 001 Device 003: ID 0bda:b711 Realtek Semiconductor Corp. RTL8188GU 802.11n WLAN Adapter (After Modeswitch)
...

This confirms that indeed I have a RTL8188GU (ID 0bda:b711).

Step 2 – Mapping the driver used

If the Kernel identified it, it might have tried to load a driver. To check that I run dmesg | grep firmware which gave me the following output:

debian@BeagleBone:~$ dmesg | grep firmware
[ 19.272516] systemd[1]: systemd-pcrmachine.service - TPM2 PCR Machine ID Measurement was skipped because of an unmet condition check (ConditionPathExists=/sys/firmware/efi/efivars/StubPcrKernelImage-4a67b082-0a4c-41cf-b6c7-440b29bb8c4f).
[ 35.452599] remoteproc remoteproc0: Booting fw image am335x-pm-firmware.elf, size 217148
[ 236.783513] usb 1-1: rtl8xxxu: Loading firmware rtlwifi/rtl8710bufw_SMIC.bin
[ 236.801215] usb 1-1: Direct firmware load for rtlwifi/rtl8710bufw_SMIC.bin failed with error -2
[ 236.810099] usb 1-1: request_firmware(rtlwifi/rtl8710bufw_SMIC.bin) failed
[ 236.819474] usb 1-1: Fatal - failed to load firmware

The most important part are these three lines:

[ 236.783513] usb 1-1: rtl8xxxu: Loading firmware rtlwifi/rtl8710bufw_SMIC.bin
[ 236.801215] usb 1-1: Direct firmware load for rtlwifi/rtl8710bufw_SMIC.bin failed with error -2
[ 236.810099] usb 1-1: request_firmware(rtlwifi/rtl8710bufw_SMIC.bin) failed

They informed that the Kernel has the driver rtl8xxxu that tried, and failed, to load the corresponding firmware rtl8710bufw_SMIC.bin. The file rtl8710bufw_SMIC.bin is specified in the Linux Kernel.

One could argue and say that I have the RTL8188GU but the kernel is loading the firmware for RTL8710BU. This is because Realtek use many chips with similar names and a generic driver (rtl8xxxu) that is suppose to server the many models. The exact correspondence one can know by checking the driver source-code or messages from dmesg, as I did.

Note that your dmesg timestamps (these things at the beginning of each line[ 236.810099]) may differ depending on when the dongle is initialized.

Coming back to the firmware file (rtl8710bufw_SMIC.bin), I confirmed that I didn’t have it with ls -l /lib/firmware/rtlwifi:

debian@BeagleBone:~$ ls -l /lib/firmware/rtlwifi
total 1040
-rw-r--r-- 1 root root  11216 May  1  2023 rtl8188efw.bin
-rw-r--r-- 1 root root  13904 May  1  2023 rtl8188eufw.bin
-rw-r--r-- 1 root root  16192 May  1  2023 rtl8192cfw.bin
-rw-r--r-- 1 root root  14818 May  1  2023 rtl8192cfwU.bin
-rw-r--r-- 1 root root  16332 May  1  2023 rtl8192cfwU_B.bin
-rw-r--r-- 1 root root  16014 May  1  2023 rtl8192cufw.bin
-rw-r--r-- 1 root root  16126 May  1  2023 rtl8192cufw_A.bin
-rw-r--r-- 1 root root  16096 May  1  2023 rtl8192cufw_B.bin
-rw-r--r-- 1 root root  16126 May  1  2023 rtl8192cufw_TMSC.bin
-rw-r--r-- 1 root root  31376 May  1  2023 rtl8192defw.bin
lrwxrwxrwx 1 root root     17 May  1  2023 rtl8192eefw.bin -> rtl8192eu_nic.bin
-rw-r--r-- 1 root root  25264 May  1  2023 rtl8192eu_ap_wowlan.bin
-rw-r--r-- 1 root root  32286 May  1  2023 rtl8192eu_nic.bin
-rw-r--r-- 1 root root  29008 May  1  2023 rtl8192eu_wowlan.bin
-rw-r--r-- 1 root root  80208 May  1  2023 rtl8192sefw.bin
-rw-r--r-- 1 root root 122328 May  1  2023 rtl8712u.bin
-rw-r--r-- 1 root root  22172 May  1  2023 rtl8723aufw_A.bin
-rw-r--r-- 1 root root  24118 May  1  2023 rtl8723aufw_B.bin
-rw-r--r-- 1 root root  19200 May  1  2023 rtl8723aufw_B_NoBT.bin
-rw-r--r-- 1 root root  30746 May  1  2023 rtl8723befw.bin
-rw-r--r-- 1 root root  31762 May  1  2023 rtl8723befw_36.bin
lrwxrwxrwx 1 root root     23 May  1  2023 rtl8723bs_ap_wowlan.bin -> rtl8723bu_ap_wowlan.bin
-rw-r--r-- 1 root root   9120 May  1  2023 rtl8723bs_bt.bin
lrwxrwxrwx 1 root root     17 May  1  2023 rtl8723bs_nic.bin -> rtl8723bu_nic.bin
lrwxrwxrwx 1 root root     20 May  1  2023 rtl8723bs_wowlan.bin -> rtl8723bu_wowlan.bin
-rw-r--r-- 1 root root  20886 May  1  2023 rtl8723bu_ap_wowlan.bin
-rw-r--r-- 1 root root  32108 May  1  2023 rtl8723bu_nic.bin
-rw-r--r-- 1 root root  26398 May  1  2023 rtl8723bu_wowlan.bin
-rw-r--r-- 1 root root  27726 May  1  2023 rtl8723defw.bin
-rw-r--r-- 1 root root  11662 May  1  2023 rtl8723fw.bin
-rw-r--r-- 1 root root  22996 May  1  2023 rtl8723fw_B.bin
-rw-r--r-- 1 root root  27516 May  1  2023 rtl8812aefw.bin
-rw-r--r-- 1 root root  21204 May  1  2023 rtl8812aefw_wowlan.bin
-rw-r--r-- 1 root root  28984 May  1  2023 rtl8821aefw.bin
-rw-r--r-- 1 root root  28348 May  1  2023 rtl8821aefw_29.bin
-rw-r--r-- 1 root root  19858 May  1  2023 rtl8821aefw_wowlan.bin
-rw-r--r-- 1 root root 127496 May  1  2023 rtl8822befw.bin

In Debian-based distributions (Ubuntu, Mint, etc.) there is a package called firmware-realtek with some Realtek proprietary firmwares. However, it doesn’t have the firmware rtl8710bufw_SMIC.bin I needed. One can check what is included in the package here.

The conclusion from this step is that I needed the file rtl8710bufw_SMIC.bin.

Step 3 – Installing the missing firmware

Searching on the internet I found a GitHub repo with the file. So I downloaded it to the folder /lib/firmware/rtlwifi:

$ cd /lib/firmware/rtlwifi
$ sudo wget https://github.com/Malik24626/RTL8188GU/tree/main/rtl8710bufw_SMIC.bin?raw=true -O rtl8710bufw_SMIC.bin

Make sure that you added the ?raw=true after the filename otherwise wget will download a html page. If in doubt, open the link in a browser to verify it downloads the binary and not HTML.

Later if found this FTP server with many others firmware available.

Next, you reboot:

$ sudo reboot

Step 4 – Checking if it is working

After the reboot, I checked with dmesg:

debian@BeagleBone:~$ dmesg | grep firmware
...
[   47.365423] usb 1-1: rtl8xxxu: Loading firmware rtlwifi/rtl8710bufw_SMIC.bin
...

Among other lines I saw that the firmware was loaded without errors!

So I checked if there is a wlan interface:

debian@BeagleBone:~$ iw dev
phy#0
        Interface wlan0
                ifindex 33
                wdev 0x1d
                addr 90:de:80:bc:ab:d1
                ssid altair4
                type managed
                channel 1 (2412 MHz), width: 20 MHz, center1: 2412 MHz
                txpower 30.00 dBm
                multicast TXQ:
                        qsz-byt qsz-pkt flows   drops   marks   overlmt hashcol tx-bytes        tx-packets
                        0       0       0       0       0       0       0       0               0

After setting up wpa_supplicant to connect to my local wifi, I checked if the wlan0 was getting an IP address:

debian@BeagleBone:~$ ifconfig
...
wlan0: flags=4163<UP,BROADCAST,RUNNING,MULTICAST>  mtu 1500
        inet 10.0.0.38  netmask 255.255.255.0  broadcast 10.0.0.255
        inet6 2604:3d09:37d:73e0::e9d5  prefixlen 128  scopeid 0x0<global>
        inet6 fe80::92de:80ff:febc:abd1  prefixlen 64  scopeid 0x20<link>
        inet6 2604:3d09:37d:73e0:92de:80ff:febc:abd1  prefixlen 64  scopeid 0x0<global>
        ether 90:de:80:bc:ab:d1  txqueuelen 1000  (Ethernet)
        RX packets 42572  bytes 10449360 (9.9 MiB)
        RX errors 0  dropped 0  overruns 0  frame 0
        TX packets 44733  bytes 26019255 (24.8 MiB)
        TX errors 0  dropped 0 overruns 0  carrier 0  collisions 0

Everything seemed to be in place, so I rebooted the BB a couple of times just to check that driver-firmware were working. By the way, I was still connect to my main computer through USB cable.

Step 5 - Final steps

I shutdown the BBB and disconnected the USB. Now I powered it on and tried to connect to it through SSH using the IP adress that wlan0 got, 10.0.0.38 in my case.

If you see a prompt asking for the password, it means your BBB is online using the wifi dongle. For sanity check try ping:

debian@BeagleBone:~$ ping -c 4 8.8.8.8
PING 8.8.8.8 (8.8.8.8) 56(84) bytes of data.
64 bytes from 8.8.8.8: icmp_seq=1 ttl=119 time=30.5 ms
64 bytes from 8.8.8.8: icmp_seq=2 ttl=119 time=38.6 ms
64 bytes from 8.8.8.8: icmp_seq=3 ttl=119 time=41.3 ms
64 bytes from 8.8.8.8: icmp_seq=4 ttl=119 time=64.9 ms

--- 8.8.8.8 ping statistics ---
4 packets transmitted, 4 received, 0% packet loss, time 3006ms
rtt min/avg/max/mdev = 30.500/43.815/64.882/12.794 ms

0% packet loss, this is what we wanted to see!

That is it, now the wifi dongle is working properly!

Final Considerations

  • The driver rtl8xxxu is in the Kernel, but the firmware was not included.
  • Not all the firmwares are available but default, to keep a lean distribution or because it is a proprietary software.
  • Always check lsusb and dmesg if the dongle doesn’t work properly.

What I didn’t include here was how to set up wpa_supplicant and manually get an IP address with dhclient.

This was originally published in Lot6.

Cheers!

H.
